Technical parameter table of Chinese Cummins Diesel Generator generator set
| Brand (Manufacturer) | Cummins Diesel Generator / Powered by Cummins (Cummins GOEMs) | |
| Origin of engine unit | China | |
| Unit model (Can be customized according to order requirements) | C469(Download) | |
| Machine type | The generator provides a stable AC power source like grid power, automatically adjusting fuel consumption according to load level. The generator set has a noise-canceling cover that is imported synchronously or installed domestically. | |
| Continuous capacity | 438 kVA (ISO 8528, fully tested) | |
| Spare capacity | 482 kVA (ISO 3046, fully tested) | |
| Voltage (Optional low voltage or medium voltage) | 220/380V; 230/400V; 240/415V; 3.3kV; 6.6kV; 11kV | |
| Frequency (suitable for Vietnam), Number of phases, Cosphi | 50 Hz, 3 phase, pf 0.8 | |
| Dimensions and weight of bare machine (custom production available according to premises) | 3200 *1200*1900 mm, 2852 kg | |
| Dimensions and weight of machine with case (custom production available according to premises) | 4200*1400*2050 mm, 3565 kg | |
| Cummins DCEC diesel engine | QSZ13-G2 | |
| Brushless transmitter (Custom configuration) | Vman, Mecc alte, Leroy-somer, Stamford, Marrelli, Engga, Crompton, Evotec, Genparts | |
| LCD control panel (Custom configuration) | Vman, Genparts, Deepsea, ComAp, Datakom, Emko, Smartgen, Lixise, Aspire | |
| Year of manufacture | 100% new, unused, current or later production | |
| Optional installation accessories (VinaGenset meets all requirements) | Automatic power transfer cabinets, synchronized air conditioners, grid-connected cabinets, extended chimneys, hot air exhaust boxes, all kinds of electrical cables, soundproof rooms, machine stands, trailers... | |
| Transported, put into position | Self-propelled cranes, specialized cranes (if needed), service to bring the machine into the basement or to high floors, to islands, hills, mountains, disassembly and reassembly, etc., consulting to provide full service to customers | |
| Operate the machine remotely via Smartphone | Available via SIM or Wifi internet connection (optional) | |
| Machine profile | CO, CQ, Test Report, PL, BL, User Manual | |
| Warranty (optional) | Warranty at the place of use: 24 months or 2000 hours or longer | |
| Spare parts | Widely available and easy to buy | |
| Time Order | Delivery after 1 to 45 days from signing the contract (Depending on warehouse status) | |
| Customized production | Yes, custom production of generator sets according to your brand and symbol orders | |
